Technical Lead Package Platform Engineer - San Jose, California, United States

Astera Labs San Jose, California, United States 1 month ago
Packaging & Advanced Integration

$160,000 - $200,000 USD yearly

Originally posted 22 August 2026 by the employer.

About the role

This role involves driving the development, qualification, and manufacturing of advanced FCBGA packages.

What you'll do

  • Lead FCBGA package NPI development from concept through production release.
  • Provide technical leadership in FCBGA assembly manufacturing processes and laminate substrate technologies.
  • Manage technical execution with substrate suppliers and assembly OSAT partners for schedule, quality, manufacturing readiness, and yield improvement.
  • Lead technical project management activities, including project planning, risk assessment, and cross-functional execution.
  • Lead package reliability assessment and qualification planning for FCBGA products.
  • Lead investigation and resolution of customer returns and field quality issues related to package assembly processes, materials, and workmanship.

What you'll need

  • Bachelor's degree or higher in a related field.
  • Minimum of 5 years of professional experience in electronic packaging fields.
  • Strong experience in FCBGA assembly manufacturing processes and laminate substrate technologies.
  • Proven NPI development experience for advanced flip-chip packages from definition through qualification and production release.
  • Experience with package implementation from die netlist to flip-chip package design and manufacturing.
  • Demonstrated experience managing substrate suppliers and assembly OSAT partners.
  • Strong technical project management skills, including schedule management, technical risk assessment, and issue resolution.
  • Experience managing and resolving customer returns and field quality issues related to semiconductor packaging.
  • Strong problem-solving skills with experience in root cause analysis, failure analysis, containment, corrective actions, and recurrence prevention.

Nice to have

  • Experience with Cadence Allegro Package Designer (APD) or equivalent package design tools.
  • Strong knowledge of FCBGA package reliability mechanisms, test methodologies, and qualification requirements.
  • Experience developing and executing qualification plans for FCBGA packages.
  • Experience with system-level reliability assessment of large-body FCBGA packages.
  • Subject-matter expertise in Co-Packaged Optics (CPO) and/or Near-Packaged Optics (NPO).
  • Deep technical expertise in package and substrate warpage, including characterization, modeling, material interactions, and assembly process impacts.

Skills: FCBGA packages, NPI development, assembly manufacturing processes, substrate suppliers, Co-Packaged Optics
