SiP Layout Design Engineer - MA, Wilmington, United States
$116,960 - $160,820 USD yearly
Originally posted 2 September 2026 by the employer.
This role supports the development of system-in-package products.
About the role
This role involves the layout design of System-in-Package (SiP) for advanced semiconductor packaging applications. This includes supporting the development of flip-chip packages, system-in-package products, and module-based solutions.
What you'll do
- Develop laminate, substrate, interposer, and PCB layout designs for flip-chip packages, SiP products, and module-based semiconductor solutions.
- Design and optimize routing, power and ground planes, via structures, escape routing, interconnect schemes, and substrate stack-ups.
- Collaborate with IC design, package engineering, and product engineering teams to meet product and package specifications.
- Perform design rule checks, layout verification, and design reviews.
- Support layout feasibility studies, floor planning, package architecture selection, and design trade-off analysis.
- Generate and maintain layout databases, design documentation, fabrication drawings, stack-up drawings, and design review materials.
What you'll need
- Bachelor’s degree in Electrical Engineering, Mechanical Engineering, or a related technical field.
- 5+ years of hands-on experience in laminate, substrate, PCB, or advanced package layout design.
- Strong understanding of laminate, substrate, and PCB layout principles, including routing, stack-up design, power/ground plane design, via design, impedance control, creepage/clearance, and manufacturability constraints.
- Strong knowledge of package structures, including BGA, LGA, flip-chip, system-in-package, multi-die packages, and module-based products.
- Proficiency in Cadence Allegro and CAD software.
- Familiarity with signal integrity, power integrity, thermal, mechanical, and reliability considerations in layout design.
Skills: package layout design, laminate, substrate, PCB, Cadence Allegro, system-in-package
