About the role
This role involves leading yield, quality, productivity, and cost improvement initiatives for photo/overlay metrology in HVM manufacturing and new product introduction (NPI).
What you'll do
- Lead HVM photo/overlay metrology yield, quality, productivity, and cost improvement initiatives.
- Resolve complex photo/overlay metrology issues through data-driven root-cause analysis.
- Define and deploy photo/overlay metrology Best Known Methods (BKM) across fabs for HVM and NPI.
- Act as the technical point for cross-fab, complex photo/overlay metrology customer concerns.
- Drive MOR–POR gap closure and cross-fab/node alignment in collaboration with internal teams and suppliers.
- Influence key suppliers and represent OCT in reviews, workshops, and governance forums.
What you'll need
- BS/MS/PhD in Electrical Engineering, Physics, Materials Science, Chemical Engineering, or related field.
- 5+ years (Senior) or 8+ years (Principal) experience in semiconductor photolithography in NPI/HVM manufacturing.
- Strong hands-on experience in photo/overlay metrology engineering (yield, quality, productivity, cost improvement).
- Proven experience in solving challenges involving overlay, CDU, metrology, reticle correction, MMM, destack, and yield matching.
- Experience defining and deploying Best Known Methods (BKM) across tools, nodes, or fabs.
- Ability to act as a technical point of contact for blocking issues and lead problem solving involving multiple functions.
Skills: photo metrology, overlay metrology, HVM manufacturing, CDU, reticle correction
