Principal Advanced Packaging Engineer - Taipei, Taiwan
Packaging & Advanced Integration
Originally posted 14 September 2026 by the employer — open 0 days.
About the role
What you'll do
- Lead R&D for advanced packaging of optical chips, including 2.1D, 2.5D, and 3D integration.
- Define and optimize wafer-level, panel-level, or die-level packaging process flows.
- Drive EIC-to-PIC integration and broader optical device integration efforts.
- Select and qualify packaging materials for advanced packaging.
- Characterize and continuously improve yield, reliability, and process capability for NPO and CPO packages.
- Develop and maintain packaging PDKs and design rules for NPO and CPO products.
What you'll need
- B.S., M.S., or Ph.D. in Electrical Engineering, Materials Science, Mechanical Engineering, or a related field.
- 8+ years of experience in semiconductor or advanced packaging engineering with technical leadership.
- Expertise in advanced packaging processes, including 2.5D/3D integration, flip-chip, hybrid bonding, Cu pillar, TSV, RDL, and overmold across wafer-, panel-, and die-level flows.
- Experience with silicon photonics chip packaging and EIC/PIC integration.
- Hands-on experience with advanced packaging materials, including underfill, molding compounds, dielectrics, adhesives, or optical-grade encapsulants.
- Proven track record of equipment and process qualification with OSAT or tool suppliers.
- Experience with PDK development and packaging design rule authoring.
- Strong foundation in yield analysis, reliability characterization, and process capability methodologies such as Cpk and SPC.
Nice to have
- Hands-on experience with CPO or NPO product development.
- Experience with optical coupling or waveguide alignment for photonic integration.
- Familiarity with DFM and DFT for advanced packaging.
Market context
This role has been open 0 days — well below the 56-day median for Packaging Engineering roles.
Packaging Engineering · Advanced Packaging
|
Open roles in category
289
|
Median days open
56 d
|
Median salary
$179k
|
See the full market breakdown ▾Category comparison, and who else is hiring
