This role focuses on the development and industrialization of advanced RF System-in-Package (SiP) technologies.
About the role
This role is for a Senior Manager, Package Process Development, responsible for leading the development and industrialization of advanced RF System-in-Package (SiP) technologies. This includes driving package process innovation and establishing manufacturing processes for high-volume production of RF modules and SiP products.
What you'll do
- Lead New Technology Introduction (NTI) activities for advanced RF SiP packaging platforms.
- Own development and optimization of RF SiP assembly processes, including Die Attach, Flip Chip Assembly, Wire Bonding, Wafer-Level Packaging Integration, Underfill, Encapsulation/Molding, Shielding Processes, SMT, and Board-Level Assembly.
- Lead Design of Experiments (DOE), process characterization, root cause analysis, and yield improvement initiatives.
- Drive process development activities from concept through production release and ramp-up.
- Partner with reliability and quality engineering teams to ensure package/process robustness and define package qualification requirements.
- Build and lead a high-performing package process development team, providing technical mentorship.
What you'll need
- MS or PhD in Electrical Engineering, Materials Science, Mechanical Engineering, or Chemical Engineering.
- 12+ years of semiconductor packaging experience with at least 3 years in a technical leadership or management role.
- Strong hands-on experience in RF SiP package development and assembly process engineering.
- Proven track record of successfully launching new package technologies into mass production.
- Deep understanding of semiconductor package assembly processes and equipment.
- Experience with NTI programs and technology transfer to manufacturing.
- Strong knowledge of statistical process control, DOE, FMEA, SPC, and process qualification methodologies.
- Experience working with OSATs and external manufacturing partners.
Nice to have
- Extensive experience with RF front-end modules, wireless communication products, or advanced SiP technologies.
- Knowledge of RF performance impacts associated with package structures and assembly processes.
- Experience with advanced packaging technologies such as Fan-Out Packaging, Wafer-Level Packaging (WLP), Panel-Level Packaging (PLP), Heterogeneous Integration, Multi-Chip Modules (MCM), and Embedded Component Technologies.
- Strong understanding of package reliability physics and failure mechanisms.
- Experience supporting automotive, mobile, Wi-Fi, Bluetooth, GNSS, or cellular RF products.
