About the role
This role involves leading a cross-functional team of process engineers in the development of advanced analog semiconductor technologies. You will drive process development across all process modules, managing concurrent technology programs.
What you'll do
- Lead, develop, and grow a cross-functional team of experienced process engineers spanning all major process modules.
- Lead process development and optimization across all process modules including Photolithography, CVD, PVD, Diffusion, Plasma Etch, CMP, and other relevant unit processes.
- Define and execute process integration strategies for advanced analog technology nodes.
- Enable multiple concurrent technology development programs, balancing resources and priorities to meet aggressive milestones.
- Partner with integration, yield, device, and operations teams to ensure seamless technology transfer and process readiness.
- Provide regular program updates, technology development status, and risk assessments to site leadership.
What you'll need
- Bachelor's degree in Electrical Engineering, Materials Science, Chemical Engineering, Physics, or a related technical field.
- 5 years of direct engineering team leadership or management experience within the semiconductor industry.
Nice to have
- Broad process module experience spanning multiple unit process areas within an advanced wafer fabrication environment.
- Experience leading technology development for analog, mixed-signal, or specialty semiconductor technologies.
- Familiarity with process integration and technology transfer to high-volume manufacturing.
- Track record of delivering new technology nodes or process generations on schedule and to performance specifications.
- Experience in 300mm wafer fabrication environments.
- Experience supporting multi-site or corporate-level technology benchmarking and governance.
- Strong cross-functional collaboration, communication, and project management skills.
- Proven ability to engage and present program and technology updates to site and executive leadership.
Skills: process development, Photolithography, CVD, PVD, Diffusion, Plasma Etch
