Focus on glass melting technology and high-refractive-index glass formulation for AR/MR waveguides.
About the role
This role leads the development of advanced glass substrates for AR/MR waveguides, combining glass melting technology, high-refractive-index glass formulation, and precision thickness control. You will transition lab-scale processes to 300 mm wafer platforms and high-volume production.
What you'll do
- Research and develop high-index optical glass compositions optimized for AR applications, focusing on melting and forming processes for defect reduction and optical properties. - Design and implement thickness and flatness control strategies, including TTV, wedge, and transmitted wavefront. - Develop advanced metrology and SPC systems to ensure substrate quality. - Transition lab-scale processes to 300 mm wafer platforms and collaborate with glass and equipment vendors to establish process windows and cost structures. - Partner with optics, photonics, and hardware teams to integrate substrates into AR waveguide designs and optimize for efficiency and color uniformity. - Contribute to patents and internal best-practice documentation to define substrate roadmaps.
What you'll need
- MS or PhD in Materials Science, Glass Science, Applied Physics, or related field. - Proven expertise in glass melting and forming technologies. - Hands-on experience with high-index glass development and optical-grade substrate processing. - Familiarity with NIL vs. etched grating processes and AR waveguide integration. - Strong understanding of refractive index engineering and optical performance metrics. - Proficiency in metrology for thickness, flatness, and transmitted wavefront, with the ability to scale processes from prototype to mass production.
Nice to have
- Experience with AR/MR waveguide substrates and thin-glass handling. - Knowledge of CMP/polishing, coatings, and surface quality optimization. - Background in supplier engagement and cost-performance trade-offs for large-scale glass manufacturing.
Skills: glass melting, high-index glass, 300mm, metrology, TTV
