Senior Photonic Layout Design Engineer - CA, Santa Clara, United States

NVIDIA US, CA, Santa Clara, United States 5 months ago
RF, Wireless & Photonics

$132,000 - $235,750 USD yearly

Originally posted 18 May 2026 by the employer. Relisted by the employer on 9 September 2026.

About the role

Take ownership of the physical design and verification of photonic integrated circuits (PICs), guiding designs from initial proof-of-concept phases to high-volume manufacturing readiness. Work within a multidisciplinary team focused on Silicon Photonics (SiPh) and SERDES products.

What you'll do

- Lead manual and automated layout designs for waveguides, modulators, photodetectors, and mixed-signal functions including high-speed/general I/Os and ESD structures. - Drive the tape-out process, including floor planning, waveguide routing, and mask data preparation. - Execute post-layout verification (DRC, LVS, fill, density) across multiple stepping versions and resolve layout-dependent issues prior to tape-out. - Own the layout of complex test structures, active/passive full loops, and certification vehicles with large Design of Experiments (DOEs) to optimize process windows. - Develop AI-assisted design methods, layout automation scripts, and custom Pcells to reduce development cycle times and customize DRC/LVS checking flows.

What you'll need

- BS, MS, or Ph.D. in Electrical Engineering, Physics, or a closely related field (or equivalent experience). - At least 12+ years of hands-on, full-chip layout design experience in semiconductor, analog, or silicon photonics industries. - Deep understanding of analog circuit layout, Silicon Photonic constraints, and device physics within advanced sub-micron CMOS and SiPh technologies. - Proven expertise with Cadence Virtuoso (Custom Layout, SDL) and industry-standard verification suites (Calibre, Hercules, ICV, Dracula, or Primeyield). - Strong proficiency in programming and scripting languages (Python, SKILL, Perl, TCL, or C++) for layout automation, file I/O, data processing, and tape-out flows. - Ability to optimize workflows using best-known methods (BKMs) and collaborate with integration and design rule teams to achieve high-yield manufacturing goals.

Skills: photonic integrated circuits, PIC, Silicon Photonic, Cadence Virtuoso, DRC, LVS
