Process Engineer 4 - US-CA-Fremont (1003), United States
$104,000 - $231,000 USD yearly
Originally posted 27 July 2026 by the employer.
About the role
As a Process Engineer, you will operate on technology, harnessing atomic precision, material science, and surface engineering to push technical boundaries. You will directly contribute to the OCTO Pathfinding team.
What you'll do
- Conduct process engineering research, development, and evaluation in support of semiconductor equipment and systems.
- Review and enhance processing techniques and methods applied in the manufacture and fabrication of products.
- Develop and sustain new processes and process improvements to reduce production costs and increase yields.
- Compile and analyze test data to establish next steps in process development and determine appropriate limits and variables for process specifications.
- Collaborate internally to plan, collect data, analyze results, and report on customer demos for existing process applications.
- Contribute to product development and release activities supporting the semiconductor roadmap.
What you'll need
- Master’s degree in Materials Science, Chemical Engineering, Chemistry or Physics or related field with 6+ years of experience; or a PhD with 3+ years’ experience; or equivalent experience.
Nice to have
- Working in a laboratory and on semiconductor equipment with experience in surface preparation and analytical techniques.
- In-depth understanding of Statistical Process Control (SPC) and/or Design of Experiments (DOE).
- Highly proficient in MATLAB, Python, or other similar scientific computing language.
- Working knowledge of statistical analysis and problem-solving methodologies.
- Experience with statistical tools (JMP, Minitab, etc.).
- Background in Atomic Layer Deposition (ALD), Chemical Vapor Deposition (CVD), Plasma Enhanced Chemical Vapor Deposition (PECVD), or Physical Vapor Deposition (PVD).
- Background in Plasma Physics, Reactive Ion Etching (RIE), Atomic Layer Etching (ALE), Inductively Coupled Plasma (ICP), Capacitively Coupled Plasma (CCP).
- Knowledge of Material synthesis and material characterization.
- Experience working in a collaborative and matrixed environment with diverse teams, semiconductor customers, and/or partners.
- Experience in semiconductor, process design, deposition, etch dielectrics or conductor, metal films.
Skills: process engineering research, processing techniques, Atomic Layer Deposition, Chemical Vapor Deposition, Plasma Etching
