This role defines and develops inspection and metrology systems for advanced substrates.

About the role

This role involves defining novel inspection systems concepts and configurations, and developing new or modified inspection and metrology systems.

What you'll do

  • Define novel inspection systems concepts and configurations.
  • Collect, analyze data, and design statistically valid experiments.
  • Design and engineer modules; qualify modules/sub-modules.
  • Develop new or modified inspection and metrology systems.
  • Perform research and analysis in physics or related subjects.
  • Define system requirements and specifications.

What you'll need

  • Experience in defining novel inspection systems concepts and configurations.
  • Ability to collect, analyze data, and design statistically valid experiments.
  • Expertise in designing and engineering modules.
  • Proven ability to develop new or modified inspection and metrology systems.
  • Skill in performing research and analysis in physics or related subjects.
  • Capability to define system requirements and specifications.

Nice to have

  • Experience guiding less experienced physicists/scientists.
  • Ability to evaluate new technologies and pursue innovative solutions.
  • Experience planning projects involving definitions and selection of new concepts in physics.

Skills: inspection systems, metrology systems, physics, modules, statistically valid experiments
